X4218 350KV Brushless Fpv Drone Motors – High-Efficiency Long-Range FPV Motor (EM Series)
Product Overview
The Fpv Drone Motors X4218 350KV is a new addition to the EM Series, specifically engineered for long-range FPV drones. Featuring a high-torque magnetic circuit design and a robust M6 steel shaft, this motor delivers exceptional efficiency and reliability for extended flights with 13–15 inch propellers. Whether you’re building a heavy-lift cruiser or an ultra-endurance long-range platform, the X4218 provides the power and precision you need.
Fpv Drone Motors Key Features
- Optimized for Long-Range Efficiency – Designed with a high-torque magnetic circuit to maximize thrust while minimizing power consumption.
- High-Strength M6 Steel Shaft – Ensures durability and impact resistance during hard landings or rough handling.
- Premium Components:
- N52H arc magnets for strong magnetic flux and consistent performance.
- NMB bearings for ultra-smooth rotation and extended lifespan.
- Multi-strand copper winding reduces resistance and improves thermal management.
- Robust Construction – CNC-machined housing with a standard 30×30mm mounting pattern, compatible with most mid-to-large frames.
- High Voltage Support – Optimized for 8S LiPo (33.6V) operation, delivering up to 1800W of peak power.
- Long Silicone Wires – 800mm 14AWG leads for easy installation on large airframes.
- New EM series motors designed for long-range FPV
- High-strength M6 steel shaft
- High torque magnetic circuit design
- Model: X4218 350KV Motor
- KV: 350KV
- Max Watt: 1800W
- Peak Current: 60A
- Interphase Resistance: 50mΩ
- Propeller: 13-15inch Propeller
- Magnet: N52H
- Bearing Type: NMB
- Configuration: 12N14P
- Dimension: 49mmx40.1mm
- Shaft Diameter: 6mm
- Shaft Protruding Length: 22.9mm
- Mounting Holes: 30mmx30mm
- Lead: 800mm/14AWG
- Compatible ESC: 60A-80A
- Input Volts: 33.6V(8S LiPo)
- Winding: Many-strand copper winding
- Included Screws: Semi-spherical Head M4*10 (4PCS)/M6 Flange Nut (1PCS)
- Weight: 289g(included wire)
- Compatible models: 13-15 inch long-range FPV
Fpv Drone Motors Technical Specifications
| Parameter | Value |
|---|---|
| Model | X4218 350KV |
| KV Rating | 350 RPM/V |
| Max Power | 1800W |
| Peak Current | 60A |
| Interphase Resistance | 50mΩ |
| Recommended Propeller | 13″ – 15″ |
| Magnet Type | N52H |
| Bearings | NMB |
| Pole/Slot Configuration | 12N14P |
| Dimensions (Diameter × Height) | φ49mm × 40.1mm |
| Shaft Diameter | φ6mm |
| Shaft Protruding Length | 22.9mm |
| Mounting Hole Pattern | 30mm × 30mm (M4 screws) |
| Wire Gauge & Length | 14AWG, 800mm |
| Compatible ESC | 60A – 80A |
| Input Voltage | 33.6V (8S LiPo) |
| Winding Type | Multi-strand copper winding |
| Included Screws | 4 × M4×10 (semi-spherical head) 1 × M6 flange nut |
| Weight | 289g (including wires) |
| Compatible Models | 13″ – 15″ long-range FPV drones, heavy-lift platforms |
Fpv Drone Motors Recommended Applications
- Drone Type: Long-range FPV, endurance cruisers, heavy-lift multirotors
- Frame Size: Suitable for 13–15 inch propeller setups
- Propeller Size: 13–15 inches (choose based on desired thrust/efficiency)
- ESC Requirement: 60A–80A (ensure good thermal management)
- Battery: 8S LiPo for optimal performance
Package Includes
- 1 × X4218 350KV Brushless Motor
- 4 × M4×10 mounting screws (semi-spherical head)
- 1 × M6 flange nut
- (Motor wires pre-installed with 14AWG silicone cable)
This Fpv Drone Motors X4218 350KV motor is a perfect choice for pilots seeking a reliable, efficient, and powerful solution for their long-range FPV builds.
