Brushless Fpv Motor 3115 640KV 900kv 3-6S 9inch 10Inch 11Inch RC Long Range Quadcopter uav drone electric motors

Tracker 3115 Brushless Fpv Motor – High-Performance Motor for 9 10 11 Inch FPV Racing & Long-Range Quadcopters

---

Fpv Motor Product Overview

The Tracker 3115 Brushless Motor is a powerful and efficient motor designed for 9-inch to 11-inch FPV racing and long-range drones. Available in 640KV and 900KV options, this motor is built for high thrust and endurance. Featuring a 12N14P configuration, 0.2mm Kawasaki silicon steel stator, Japanese NMB bearings, N52H arc magnets, and a titanium alloy hollow shaft, the Tracker 3115 delivers exceptional performance, durability, and weight savings for demanding flight applications.

---

Fpv Motor Key Features

• Multiple KV Options – Available in 640KV and 900KV to suit various propeller sizes and flight styles.
• Lightweight Titanium Shaft – Titanium alloy hollow shaft reduces weight while maintaining high strength.
• High-Quality Stator – 0.2mm Kawasaki silicon steel stator for improved efficiency and reduced eddy current losses.
• Precision Bearings – Japanese NMB bearings (11×5×5mm) for smooth rotation and long service life.
• Powerful Magnets – N52H arc magnets deliver strong magnetic flux for excellent torque and responsiveness.
• Durable Construction – 7075 aluminum bell cap and base casing provide superior strength and heat dissipation.
• Secure Prop Mounting – M5 prop adapter shaft thread for reliable propeller attachment.
• Standard Bolt Pattern – M3 (19×19mm) mounting pattern for compatibility with common frames.
• Long Silicone Wires – 18AWG silicone wires with 25cm length for easy installation in larger frames.
• Lightweight Design – Only 110g (with 25cm silicone wires), ideal for long-range efficiency.

---

Fpv Motor Technical Specifications

Parameter	Value
Series	Tracker
KV Options	640KV / 900KV
Base Casing Material	7075 Aluminum
Stator Material	0.2mm Kawasaki silicon steel
Configuration	12N14P
Prop Adapter Shaft Thread	M5
Shaft Material	Titanium Alloy (hollow shaft)
Bolt Pattern	M3 (19×19mm)
Bearings	Japanese NMB (11×5×5mm)
Rotor Magnets	N52H arc magnets
Weight	110g (with 25cm silicone wires)
Wire Gauge & Length	18AWG, 25cm
Bell Cap Material	7075 Aluminum

---

Recommended Configuration (Not Included)

Component	Recommendation
ESC	50A – 70A (matched to KV and propeller selection)
Propeller	9-inch / 10-inch / 11-inch (dependent on KV)
Flight Controller	F4 / F7 / KK / SpeedyBee F405 / F722 / compatible controllers
Applicable Drone Sizes	9-inch, 10-inch, 11-inch

---

KV Selection Guide

KV	Recommended Propeller	Recommended Voltage	Application
640KV	10-inch / 11-inch	6S – 8S	Long-range efficiency, heavy-lift, endurance
900KV	9-inch / 10-inch	6S	Balanced performance for racing and long-range

---

Recommended Applications

• Drone Types: FPV Racing, Long-Range, Cinematic, Heavy-Lift
• Frame Compatibility: 9 10 11 inch FPV frames
• Propeller Compatibility: 9 10 11 inch propellers depending on KV selection
• Power Systems: Suitable for 6S–8S LiPo setups with appropriate ESC

---

Package Includes

• 1 × Tracker 3115 Brushless Motor
• (Mounting hardware, prop adapter, and accessories may vary; check with seller)

---

Fpv Motor Summary

The Tracker 3115 Brushless Motor is a high-performance powerplant designed for FPV pilots building 9–11 inch racing and long-range drones. With dual KV options, premium materials including Kawasaki silicon steel stator, NMB bearings, N52H magnets, and a lightweight titanium alloy hollow shaft, this motor delivers reliable thrust, efficient power delivery, and exceptional durability. Whether racing at high speeds or cruising long distances, the Tracker 3115 provides the performance required for demanding FPV applications.

Tracker 3115 – Aerospace‑Grade Power for 9–11″ Long‑Range & Heavy‑Lift Fpv Motor

When you need to swing large 9–11″ propellers with confidence, the Tracker 3115 delivers unmatched torque and durability. Engineered from premium materials and featuring a unique titanium alloy hollow shaft, this motor is built for endurance, heavy payloads, and demanding long‑range missions.

Key advantages:

• Optimized for 9–11″ props – Perfect for large long‑range cruisers, cinema rigs, X‑class racers, and industrial survey drones.
• Two KV options, one platform
  – 640KV – Ideal for 6‑8S setups with 10–11″ props (max efficiency & flight time)
  – 900KV – Great for 5‑6S builds with 9–10″ props (more responsive, spirited flying)
• Titanium alloy hollow shaft – Ultra‑strong, lightweight, and corrosion‑resistant. Hollow design reduces rotating mass for quicker throttle response while maintaining crash resilience.
• Aerospace 7075 aluminum – Both bell cap and base casing are CNC‑machined from 7075 alloy, offering superior strength and thermal conductivity over standard 6061.
• 0.2mm Kawasaki silicon steel stator – Low eddy current losses keep efficiency high and temperatures low during sustained climbs or heavy payloads.
• N52H arc magnets – Highest grade neodymium magnets provide maximum torque density without increasing motor size.
• Oversized Japanese NMB bearings (11x5x5mm) – Greater load capacity ensures smooth operation and long life under high thrust.
• Standard 19×19mm M3 mounting – Compatible with all full‑size frames (Mark4, Apex, LR, and XL frames).
• M5 prop shaft thread – Industry standard for 9–11″ props, compatible with carbon, folding, and multi‑blade propellers.
• Robust electrical design – 12N14P topology, 18AWG 250mm silicone leads, and 110g weight (with wires) for an excellent power‑to‑weight ratio.

Recommended pairings:

• ESC: 50A–70A (BLS 60A/80A/100A recommended for 640KV on 8S)
• Flight controllers: F4, F7, SpeedyBee F405/F722, KK
• Propellers: 9″, 10″, or 11″ depending on KV and battery

Whether you’re flying a 10″ long‑range quad loaded with Li‑ion packs or building a heavy‑lift cinema drone, the Tracker 3115 delivers the torque, thermal headroom, and build quality to go the distance.
